TANK WEIGHING SYSTEM

Applications:

  • Perfume Mixing
  • Low Viscous Liquid Mixing
  • Non Foaming Liquid Mixing
  • Liquid Mixing
Category:
SHARE

Description

Technical Specifications
Capacity (Model) 125LTRS 225LTRS 300LTRS 500LTRS
Gross Capacity 160ltrs 275Ltrs 350Ltrs 575Ltrs
Net Capacity 125ltrs 225Ltrs. 300Ltrs 500Ltrs.
Shell With Dish (mm) 500 Ø x 810H 637 Ø x 960H 720 Ø x 960H 796 Ø x 1250H
Overall Wall Thickness. 1.6-2mm 2-2.5mm 2 – 2.5mm 2 – 2.5mm
Total Height 1425mm 1525mm 1800mm 1950mm
Geared Motor Capacity 0.25HP/ 380V/ 440V 0.25HP/ 380V/ 440V 0.25HP/ 380V/ 440V 0.25HP/ 380V/ 440V
Rpm`(Fix) 100-140 100-140 100-140 100-140
Outlet Butterfly/Ball Valve DIN 25mm S.S.304 DIN 25mm S.S.304 DIN 25mm S.S.304 DIN 25mm S.S.304
M.O.C. For Gasket & Seal Silicone/ Viton/PTFE Silicone/ Viton/PTFE Silicone/ Viton/PTFE Silicone/ Viton/PTFE
Main Hole With Lid (MM) 300Dia.Round 300Dia.Round 300Dia.Round 300Dia.Round
